Event Icon Examples
Alarms
Varies by alarm state
• Alarms occurring in the system
• Alarms being acknowledged by the user
• Alarm condition going back to normal
Info • Parameter change(s)
Command • Push-button actions
11.2 Log
11.2.1 Review log events
Events that occur during the operation of the controller are recorded in the event log.
View the events that have occurred in the system under Log.
Reviewing log events
To view a log entry, perform the following steps:
1. Select Log to view the event log.
2. Scroll through the event log by pressing Up
or Down .
3. Select an event by pressing OK
.
4. Select either Info or Diagram by pressing Up or Down and pressing OK .
5. Further details of the event are shown on the display.
PPM 300 Operator's manual 4189340910 UK
