7.7 Digital output (DO)
7.7.1 Configure I/O name
To rename the input or output name:
1. Select I/O name
.
• The virtual keyboard is displayed on screen to edit the I/O name.
•
2. Enter the required I/O name and select Write
.
7.7.2 View or configure I/O relay
You can configure the setting for the relay. The current configure state for the relay is shown on the display. By default all
relays are considered to be Normally open and in a De-energised state.
From this screen you can configure either a standard relay or a changeover relay, depending upon the type of relay that can
be connected to the hardware module terminals.
PPM 300 Operator's manual 4189340910 UK
www.deif.com Page 77 of 157
