Table 7.1 Configuration for the uses of an analogue input
Use Functions* Sensor setup* Alarms*
Analogue function(s) ● ● ○
Digital function(s) ● ● ○
Sensor failure ○ ● ○
Alarm(s) ○ ● ●
*Note: ● represents required configuration. ○ represents optional configuration.
7.8.2 Configure Analogue input (AI)
To configure the analogue input (AI) you need to do the following:
1. Select the hardware module, terminal(s), for an Analogue input (AI) to be used.
• Optional: You can configure the I/O name.
• See Analogue input (AI), Configure I/O name.
2. If required, select the input function(s) (y-axis).
• These can be either Analogue function(s) or Supervised binary input function(s).
•
See Analogue input (AI), Configure function(s) for how to select the function(s).
3. Configure the Sensor settings and curve (x-axis).
• You can use a predefined curve or reuse/configure a custom curve.
• See Analogue input (AI), View or configure Sensor for how to configure the Sensor curve.
4. If required, configure custom alarm(s).
• See Analogue input (AI), Configure alarm(s) for how to configure the alarm(s).
As you complete each configuration, write the settings to the controller.
7.8.3 Configure I/O name
To rename the input or output name:
1. Select I/O name
.
• The virtual keyboard is displayed on screen to edit the I/O name.
PPM 300 Operator's manual 4189340910 UK
www.deif.com Page 81 of 157
