5. Highlight the parameter group you wish to open, by pressing Up or Down .
6. Select the highlighted parameter group by pressing OK .
• The parameter settings are shown on the display.
7. To highlight the parameter, select Up or Down , by pressing .
8. To highlight the parameter settings, press Up or Down .
9. Change the setting, by pressing OK .
• If the setting can be toggled, you can use Toggle
, by pressing .
• If the setting is text or a value, pressing OK displays the virtual keyboard to alter the setting.
◦ The parameter settings minimum, maximum and default are also shown.
◦ Use the Virtual keyboard to make the required changes.
◦ To confirm the setting, select Write
, by pressing .
• If the setting is a selection, pressing OK displays an available list of selection options.
◦ Highlight the option required, by pressing Up
or Down .
◦
Select the option, by pressing OK
.
◦ To confirm the setting, select Write
, by pressing .
7.5 Input/output
7.5.1 Configure Input/output
Configure I/O settings under
Configure > Input/Output.
You can configure the I/O settings and terminals for any of the hardware modules within the connected controller.
See
Hardware characteristics, in the Designer's handbook for more information regarding the different
hardware modules and their terminal details.
To configure the I/O settings you need to perform the following steps:
1. Select hardware module to configure
2. Select terminal(s) to configure
3. Configure the terminal(s) settings
7.5.2 Selecting a hardware module
Before you can configure the I/O settings, you first need to select the hardware module in the controller.
PPM 300 Operator's manual 4189340910 UK
www.deif.com Page 69 of 157
