3. Controller equipment
3.1 Display unit
3.1.1 Introduction to the display unit
The front of the display unit consists of a top part and a bottom strip.
Figure 3.1
Display unit parts
1
2
No.
1 Top part
2 Bottom strip
The LEDs and push-buttons for the top part are the same for all controller types. The LEDs, push-buttons and picture on the
bottom strip vary according to the controller type. These are described below.
