INFO
These settings cannot be configured here and must be configured in the Parameters page.
4. Select the alarm, by pressing OK .
• The selected alarm is shown with a solid box.
• To remove the selection, press OK again.
5. To save the settings to the controller, select Write
Write
.
• This only saves the selected alarm(s) and their settings to the controller. It does not save other I/O settings.
Clear all enabled alarm(s)
1. To clear all the selected alarms, select Clear
Clear
.
2. To save the new setting to the controller, select Write
Write
.
• This only saves the selected alarm(s) and their settings to the controller. It does not save other I/O settings.
7.8 Analogue input (AI)
7.8.1
Introduction to analogue inputs
You can use an analogue input for the following:
• As an input for one or more controller analogue functions.
• As a supervised input for one or more controller digital functions.
• To detect sensor failure.
• As the basis for one or more alarms.
For each analogue input use, the table below shows which pages in the analogue input view you must configure.
