Status text Description
SG in operation (base
load)
The shaft generator is producing power,
and shaft generator breaker is closed. The
base load parameter is activated.
●
SG in PTH operation
Power take home has been activated, and
shaft generator breaker is closed.
●
SG not ready
The shaft generator is not ready to provide
power to the busbar. There may be alarms
blocking the shaft generator breaker from
closing.
●
SG ready
The shaft generator is ready to provide
power to the busbar. The shaft generator
breaker may be closed.
●
SG ready for PTH
operation
Power take home has been activated, and
shaft generator breaker is open.
●
SG running
The shaft generator is producing power,
and shaft generator breaker is open.
●
Ship-to-ship active
Ship-to-ship operation is active and the
shore connection breaker is closed.
●
Starting genset in -
remaining time
Displays the remaining time (in seconds)
before the genset starts.
● ●
Start prepare -
remaining time
Displays the remaining time (in seconds)
for the genset to prepare to start.
● ●
Stop coil activated -
remaining time
Displays the remaining time (in seconds)
before the genset shuts down.
● ●
Stopping genset in -
remaining time
Displays the remaining time (in seconds)
before the genset stops.
● ●
Switchboard control
The controller is under switchboard control
and can only receive commands from the
switchboard. Power management is not
active.
● ● ● ● ●
Synchronising SCB /
SGB / BTB
The controller is busy synchronising the
busbar frequency and voltage across
busbar sections to close the external
breaker.
● ● ● ● ●
Synchronising GB
The controller is busy synchronising the
genset to the busbar frequency and
voltage to close the generator breaker.
● ●
Synchronising SGB
The genset is busy synchronising the
busbar frequency and voltage to close the
shaft generator breaker.
● ●
Synchronising TB
The controller is busy synchronising the
genset to the busbar frequency and
voltage to close the tie breaker.
●
Synchronising
sections
The two sections about to be connected
by a bus tie breaker are being
synchronised to close the bus tie breaker.
●
Waiting for software A software update is in progress. ● ● ● ● ●
