6159930310_07_01/2016- 20 -
6 - PSET
Path: Main menu / Conguration / Pset
A Parameter set is commonly called Pset and
shown by this icon.
A Pset is combining one or several steps, each step
describing a function. The tool will execute the steps one
after the other in the given order. Content of the steps and the
order can be changed at any time.
The minimum to run the tool is 1 Pset containing 1 step.
There are up to 250 Psets per tightening unit.
to go to the rst Pset
to go to the previous Pset
to go to the next Pset
to go to the last Pset
• Once the programming is done, tap this icon to
save the changes in the controller and quit the
screen.
6.1 - How to add a Pset
• Select rst the Tightening Unit. The list of Psets
can be different per Tightening Unit.
• Tap this icon to add a Pset.
6.1.1 - Expert mode
• Tap «Expert mode» to create a new Pset and add it in the
list of Psets.
6.1.2 - Simple mode
• Tap «Simple mode» to create a new Pset and quickly set it
up.
• Use the left, right or down arrow keys to display the next
screens.
• Enter the Target torque.
• Customize the Pset name.
The tightening strategy is «Torque control».
Tolerances, curves and speeds are automatically calculated.
