6159930310_07_01/2016- 50 -
11.2.5 - Tool monitoring
Path: Main menu / Maintenance / Tool
• Use the left, right or down arrow keys to navigate from one
screen to another.
11.2.6 - Transducer
Calibration data are given per transducer and per tool.
11.2.7 - Temperature
The following information are displayed:
- Motor temperature limit
- Temperature Alarm Release Limit
11.2.8 - Tool counters
Path: Main menu / Maintenance / Tool
Total counter
Number of tightenings and run reverses
above the tool min. torque since the
manufacturing date.
Partial counter
Number of tightenings and run
reverses since the last reset by using
CVIMONITOR.
• Use the left, right or down arrow keys to navigate from one
screen to another.
11.2.9 - Maintenance alarms
• Launch CVIMONITOR software to reset the partial counters
and change the parameters.
Pop-ups are automatically displayed to alert the
user to perform maintenance.
• Refer to "Appendix - Spare parts" to get more
information.
