Desoutter CVI3 Vision User Manual

Appendix B - JVL6-32 Residual Current Circuit
Breaker_01/2016
- 89 -
APPENDIX B - JVL6-32 RESIDUAL CURRENT CIRCUIT BREAKER
The CVI3 has a JVL6-32 residual current circuit breaker with
over-current Protection.
The residual current circuit breaker must be tested monthly.
It provides protection against earth leakage faults (30mA),
overloads, short-circuits and Over-current in your installation
(I=16A. see curve).
The Over-current protection of the JVL6-32 uses “D” tripping
characteristics
FIGURE 1 – CURVE C AND D
