LEFT REAR SIDE MARKER LAMP (DODGE) - NATURAL 2 WAY
CAV CIRCUIT FUNCTION
1 Z1 18BK GROUND
2 L7 18BK/YL PARK LAMP RELAY OUTPUT
LEFT REAR TURN SIGNAL LAMP (300M/BUILT-UP-EXPORT)-3WAY
CAV CIRCUIT FUNCTION
1 L61 18LG/TN LEFT TURN SIGNAL
2- -
3 Z1 18BK GROUND
LEFT REAR TURN SIGNAL LAMP (DODGE) - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 L61 18LG/TN LEFT TURN SIGNAL
2 Z1 18BK GROUND
LEFT REAR TURN SIGNAL LAMP (LTD)-2WAY
CAV CIRCUIT FUNCTION
1 L61 18LG/TN LEFT TURN SIGNAL
2 Z1 18BK GROUND
LEFT REAR WHEEL SPEED SENSOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 B4 18LG LEFT REAR WHEEL SPEED SENSOR (+)
2 B3 18LG/DB LEFT REAR WHEEL SPEED SENSOR (-)
LH 8W-80 CONNECTOR PIN-OUTS 8W - 80 - 65
