PASSENGER POWER SEAT HORIZONTAL MOTOR - BLACK 2 WAY
CAV CIRCUIT FUNCTION
1 P14 16YL/LB PASSENGER SEAT HORIZONTAL FORWARD
2 P16 16RD/LB PASSENGER SEAT HORIZONTAL FORWARD
PASSENGER POWER SEAT REAR RISER MOTOR-2WAY
CAV CIRCUIT FUNCTION
1 P10 16YL/WT PASSENGER SEAT REAR UP
2 P12 16RD/WT PASSENGER SEAT REAR DOWN
PASSENGER POWER SEAT RECLINER MOTOR - GREEN 2 WAY
CAV CIRCUIT FUNCTION
1 P42 16GY/BK PASSENGER SEAT RECLINER SWITCH DOWN
2 P44 16GY/DB PASSENGER SEAT RECLINER SWITCH UP
PASSENGER POWER SEAT SWITCH - BLUE 10 WAY
CAV CIRCUIT FUNCTION
1 F35 16RD FUSED B(+)
2 P42 16GY/BK PASSENGER SEAT RECLINER SWITCH DOWN
3 P16 16RD/LB PASSENGER SEAT HORIZONTAL FORWARD
4 P44 16GY/DB PASSENGER SEAT RECLINER SWITCH UP
5 Z1 16BK GROUND
6 P18 16YL/LG PASSENGER SEAT FRONT UP
7 P10 16YL/WT PASSENGER SEAT REAR UP
8 P12 16RD/WT PASSENGER SEAT FRONT DOWN
9 P20 16RD/LG PASSENGER SEAT FRONT DOWN
10 P14 16YL/LB PASSENGER SEAT HORIZONTAL FORWARD
PASSENGER POWER WINDOW MOTOR - RED 2 WAY
CAV CIRCUIT FUNCTION
1 Q22 16VT PASSENGER WINDOW DRIVER (DOWN)
2 Q12 16BR PASSENGER WINDOW DRIVER (UP)
LH 8W-80 CONNECTOR PIN-OUTS 8W - 80 - 77
