(11) Remove low/reverse accumulator piston and
springs (Fig. 23) (Fig. 24).
(12) Remove long stub shaft bearing snap ring
(Fig. 25).
(13) Remove long stub shaft and bearing from bell-
housing using Tools 8420A and C-3752 (Fig. 26).
Fig. 23 Remove Low/Reverse Accumulator Piston
1 - SEAL RINGS
2 - PISTON
3 - PISTON
4 - PETROLATUM
5 - SUITABLE TOOL
Fig. 24 Low/Reverse Accumulator Components
1 - ACCUMULATOR PISTON
2 - SEAL RINGS
3 - RETURN SPRINGS
4 - (NOTE NOTCH)
Fig. 25 Remove Long Stub Shaft Snap Ring
1 - SNAP RING
2 - SNAP RING PLIERS
3 - LONG STUB SHAFT
Fig. 26 Remove Long Stub Shaft From Bellhousing
1 - LONG STUB SHAFT
2 - SPECIAL TOOL 8420A
3 - SLIDE HAMMER C-3752
LH TRANSAXLE 21 - 15
42LE AUTOMATIC TRANSAXLE (Continued)
