(14) Remove oil pump-to-case bolts (Fig. 27).
(15) Remove oil pump using C-3752 Pullers (Fig.
28).
(16) Remove oil pump while pushing in on input
shaft (Fig. 29).
(17) Remove oil pump gasket (Fig. 30).
CAUTION: By-pass valve must be replaced if trans-
mission failure occurs.
Fig. 27 Remove Oil Pump Attaching Bolts
1 - BELLHOUSING
2 - OIL PUMP
Fig. 28 Oil Pump Pullers
1 - OIL PUMP
2 - PULLERS
Fig. 29 Remove Oil Pump
1 - “PUSH IN” ON INPUT SHAFT WHILE REMOVING PUMP
Fig. 30 Remove Oil Pump Gasket
1 - BELL HOUSING
2 - OIL PUMP GASKET
21 - 16 TRANSAXLE LH
42LE AUTOMATIC TRANSAXLE (Continued)
