(47) Use special tool 6597 and handle C-4171 and
C-4171-2 to press rear output shaft bearing cup rear-
ward (Fig. 64).
(48) Remove rear carrier front bearing cone (Fig.
65).
(49) Install and load compressor (Fig. 66) as shown
in (Fig. 67).
Fig. 63 Remove Front Bearing Cup
1 - ARBOR PRESS
2 - SPECIAL TOOL 6596
Fig. 64 Remove Rear Bearing Cup
1 - SPECIAL TOOL 4171 AND 4171–2
2 - SPECIAL TOOL 6597
Fig. 65 Remove Rear Carrier Front Bearing Cone
1 - SPECIAL TOOL 5048–1
2 - SPECIAL TOOL 6545
3 - REAR CARRIER
4 - SPECIAL TOOL 5048
Fig. 66 Low/Reverse Spring Compressor Tool
1 - TOOL 6057
2 - TOOL 5059
3 - TOOL 5058–3
LH TRANSAXLE 21 - 25
42LE AUTOMATIC TRANSAXLE (Continued)
