(23) Install low/reverse clutch pack (Fig. 109).
Leave uppermost disc out to facilitate snap ring
installation.
(24) Install low/reverse reaction plate snap ring
(Fig. 110).
(25) Install one low/reverse clutch disc (Fig. 111).
(26) Install low/reverse reaction plate with flat
side up (Fig. 112).
Fig. 109 Install Low/Reverse Clutch Pack
1 - CLUTCH PLATES (5)
2 - CLUTCH DISCS (5)
Fig. 110 Install Low/Reverse Reaction Plate Snap
Ring
1 - SCREWDRIVER
2 - LOW/REVERSE REACTION PLATE FLAT SNAP RING
3 - DO NOT SCRATCH CLUTCH PLATE
Fig. 111 Install One Disc
1 - ONE DISC FROM LOW/REVERSE CLUTCH
Fig. 112 Install Low/Reverse Reaction Plate
1 - LOW/REVERSE REACTION PLATE (FLAT SIDE UP)
LH TRANSAXLE 21 - 37
42LE AUTOMATIC TRANSAXLE (Continued)
