(3) Using suitable pry tools, pry differential carrier
apart (Fig. 170).
(4) Remove stub shaft C-clip (Fig. 171).
(5) Using a suitable punch, remove pinion shaft
roll pin (Fig. 172).
(6) Remove differential pinion shaft. Remove pin-
ion and side gears (Fig. 173).
Fig. 170 Pry Differential Carrier Apart
1 - DIFFERENTIAL CARRIER
2-PRYTOOL
3-PRYTOOL
Fig. 171 Remove C-Clip
1 - SIDE GEAR
2 - STUB SHAFT
3 - “C” CLIP
Fig. 172 Remove Pinion Shaft Roll Pin
1 - HAMMER
2 - PIN PUNCH
3 - PINION SHAFT
4 - DIFFERENTIAL CARRIER
5 - DIFFERENTIAL BEARING
Fig. 173 Slide Out Differential Pinion Shaft and
Remove Pinion Gears and Side Gears
1 - DIFFERENTIAL CARRIER
2 - PINION SHAFT
3 - SIDE GEARS
21 - 78 TRANSAXLE LH
FINAL DRIVE (Continued)
