Dodge Intrepid - Page 638

Fig. 215 Transfer Shaft Support Fixture
1 - SUPPORT FIXTURE (6595)
Fig. 216 Seal Protector Installation
1 - SEAL PROTECTOR
2 - TRANSFER SHAFT
Fig. 217 Correct Seal Orientation
1 - SEAL PROTECTOR
2 - FRONT TRANSFER SHAFT SEAL
3 - SERRATED SIDE REARWARD
Fig. 218 Seal Installation
1 - ARBOR PRESS
2 - SEAL INSTALLER (6567A)
3 - TRANSAXLE CASE
LH TRANSAXLE 21 - 91
FINAL DRIVE (Continued)
