(10) Remove and inspect #3 & #4 thrust washers
(Fig. 270).
(11) Remove the underdrive shaft assembly (Fig.
271).
(12) Remove the #2 needle bearing (Fig. 272).
NOTE: The OD/UD Reaction Plate, Snap Rings, and
Input Clutch Retainer is not interchangeable with
previous year 41TE components. The snap rings
are thicker and the position of the ring lands have
changed.
(13) Remove the OD/UD reaction plate tapered
snap ring (Fig. 273).
Fig. 270 #3 & 4 Thrust Washers
1 - #3 THRUST PLATE (3 TABS)
2 - OD SHAFT ASSEMBLY
3 - #4 THRUST PLATE (3 SLOTS)
Fig. 271 Underdrive Shaft Assembly
1 - #3 THRUST WASHER (5 TABS)
2 - UNDERDRIVE SHAFT ASSEMBLY
Fig. 272 No. 2 Needle Bearing
1 - #2 NEEDLE BEARING (NOTE 3 TABS)
Fig. 273 Tapered Snap Ring
1 - OVERDRIVE/UNDERDRIVE CLUTCHES REACTION PLATE
TAPERED SNAP RING
2 - SCREWDRIVER (DO NOT SCRATCH REACTION PLATE)
21 - 110 TRANSAXLE LH
INPUT CLUTCH ASSEMBLY (Continued)
