PSS5000/TEMA/803046/05 21 of 152
PSS 5000 – Technical Manual
3 Configuration and Service
Functions of the
navigation buttons
In general, the navigation buttons are used as follows:
Functions of the CPU
board LEDs
The CPU board has 2 LEDs associated with the Service Panel: BOOT and AP-
PL
. These LEDs are used to indicate the status of the program:
Buttons Description
These buttons are used in the following ways:
• To move down and up through the structure of the
service menus. For example, to move from menu 1
to 2, or from menu 1.1 to 1.2.
• To move down and up through lines of data, where
each line is a separate item. For example, a line is
an individual transaction.
• To change the value of the parameter shown in the
display.
These buttons are used in the following ways:
• To move to a lower or higher level of the current
menu. For example, to move from menu 2 to 2.1.
• To move along a single line of data, for example in
a transaction log.
• Left arrow only – to return to the Idle menu from a
top level menu. For example, to move directly to
Idle from menu 2.
This button is used to accept the value of a parameter
after it has been changed.
BOOT LED APPL LED Description
Blink Off Boot running. Blink rate is according to
the current load rate.
Off Blink Appl running. Blink rate according to the
current load rate.
On Off Super Master Reset in progress. (Status
of reset shown in display).
Off Very Fast Blink Master Reset in progress (APPL).
On Off Reset in progress. (No status informa-
tion shown in display).
On On Erasing Flash (BOOT)
Alternating On Programming the Flash (APPL).
Off On APPL program stopped / Error State.
