Draytek Vigor2762 series User Manual

Web User Interface
Web User Interface
VI-
VI-
3
3
-1 Status
-1 Status
This page displays current status (online, offline or SSID hidden, IP address, encryption,
channel, version, password and etc.) of the access points managed by Vigor router. Please
open Central AP Management>>Function Support List to check what AP Models are
supported.
Available settings are explained as follows:
Item Description
Index Click the index number link for viewing the settings summary
of the access point.
Device Name The name of the AP managed by Vigor router will be
displayed here.
IP Address Display the true IP address of the access point.
SSID Display the SSID configured for the access point(s) connected
to Vigor2762.
Ch. Display the channel used by the access point.
STA List Display the number of wireless clients (stations) connecting
to the access point.
In which, 0/64 means that up to 64 clients are allowed to
connect to the access point. But, now no one connects to the
access point.
The number displayed on the left side means 2.4GHz; and the
number displayed on the right side means 5GHz.
AP List Display the number of the AP around the device.
Uptime Display the duration of the AP powered up.
Vigor2762 Series User’s Guide
345
