II-1-2-2 Details Page for M
II-1-2-2 Details Page for M
p
p
oA/Static or Dynamic IP in WAN1 (Physical Mode:
oA/Static or Dynamic IP in WAN1 (Physical Mode:
ADSL)
ADSL)
MPoA is a specification that enables ATM services to be integrated with existing LANs, which
use either Ethernet, token-ring or TCP/IP protocols. The goal of MPoA is to allow different
LANs to send packets to each other via an ATM backbone.
To use MPoA / Static or Dynamic IP as the accessing protocol of the Internet, select MPoA /
Static or Dynamic IP from the WAN>>Internet Access >>WAN1 page. The following web
page will appear.
Available settings are explained as follows:
Item Description
Enable/Disable Click Enable for activating this function. If you click
Disable, this function will be closed and all the settings that
you adjusted in this page will be invalid.
Modem Settings Set up the DSL parameters required by your ISP. These
settings configured here are specified for ADSL only.
Multi-PVC channel - The selections displayed here are
determined by the page of Internet Access >>Multi PVCs.
Select M-PVCs Channel means no selection will be chosen.
Encapsulation - Drop down the list to choose the type
provided by ISP.
VPI - Type in the value provided by ISP.
VCI - Type in the value provided by ISP.
Modulation –Default setting is Multimode. Choose the one
that fits the requirement of your router.
Vigor2762 Series User’s Guide
