There are two mounting holes for installing antennas with extension base on Vigor router.
Please install them as shown below.
Note, if only one antenna shall be installed, please use the mounting hole (major signal
transmitted hole) near to the SIM card slot.
While installing the SIM card into the card slot, note that back plate of the SIM card slot must
be removed first and the direction of card notch must be on the left side.
Extension
Base
SIM Card
Slot
Major Signal
Transmitted Hole
To Next Page
