Vigor2860 Series User’s Guide
858
voip dsp pstnringfxs [1|2] [on|off]
voip dsp relaydbounce [on|off]
voip dsp setRingPat [ring_pattern_index] [patten_num]
voip dsp setDtmfCidlevel –l [value]
voip dsp setDtmfCidlevel –h [value]
voip dsp setDtmfCidlevel –r 0
voip dsp cidplusdigit [1/0] [channel] [value]
S
S
y
y
n
n
t
t
a
a
x
x
D
D
e
e
s
s
c
c
r
r
i
i
p
p
t
t
i
i
o
o
n
n
Parameter Description
voip dsp countrytone
[channel] [value] This command allows users to set the region for the tone settings.
Different regions usually need different tone settings.
Channel – 1 or 2.
Value – displayed as follows:
[2] UK, [3] USA, [4] Denmark, [5] Italy, [6] Germany,
[7] Netherlands, [8] Portugal, [9] Sweden, [10] Australia,
[11] Slovenia, [12] Czech, [13] Slovakia, [14] Hungary,
[15] Switzerland , [16] France , [17] Malta
voip dsp dialtonepwr
channel This setting is used to adjust the loudness of the dial tone. The
smaller the number is, the louder the dial tone is. It is
recommended for you to use the default setting.
Channel - Available channel number: 1 – 2
AbsoluteValue AbsoluteValue - In -1 dB increments, with 1 corresponding to 6 dBm.
Range - 1 to 30
voip dsp EchoCanceler
type This command is used to set the type of echo reduction.
0 - Disable the LEC processing.
1 - Cancel using the fixed window.
2 - Cancel using the fixed and moving window.
3 - Cancel using fixed window + Echo Suppressor.
w_size The Line Echo Canceller (LEC) window size is 4, 6, 8 or 16 (ms).
nlp Nlp - Non-linear processing (NLP) for more smooth transitions.
1 - disable
0 - enable
voip dsp cidtype
channel Set the caller ID type for FXS 1 (Channel 1) or FXS 2 (Channel 2).
1 – FXS 1
2 – FXS 2
value Each number (1 to 6) represents different type.
1 – FSK_ETSI
2 - FSK_ETSI(UK)
3 - FSK_BELLCORE(US/AU)
4 - DTMF
5 - DTMF(Dk)
6 - DTMF(SE,NL,FIN)
For example :
