Vigor2860 Series User’s Guide
863
1 means 20ms
2 means 30ms
3 means 40ms
5 means 60ms
Vad - 0 means to Disable the function of Voice Active Detector
(vad); 1 means to Enable the function of Voice Active Detector
(vad).
One – 0 means to Disable the function of single codec; 1 means to
Enable the function of single codec.
voip rtp dtmf
[index] [mode |
payloadtype][value]
Set the DTMF mode and Payload type for DTMF.
Index – SIP account index number. Available number, 1 ~ 12.
Mode – Four options to be selected.
0. Inband
1. Outband
2. SIP INFO (cisco)
3. SIP INFO (nortel)
Payloadtype – Available settings 96~127.
Value – Type 0~3 or 96~127 based on the mode specified.
For example,
> voip rtp dtmf 1 mode 1
voip rtp port
start|end Specifies the start/end port for RTP stream.
value The default value is 10050/15000.
voip rtp symmetric
value Make the data transmission going through on both ends of local
router and remote router not misleading due to IP lost.
1 – Enable
0 - Disable
voip rtp tos
value Set the type of service (TOS) setting for RTP packets.
For example,
> voip rtp tos 0x899
Set TOS: 0x899
E
E
x
x
a
a
m
m
p
p
l
l
e
e
> voip rtp codec 1 type 3
> voip rtp dtmf 2 mode 3
>
voip rtp port start 10070 end 14400
Set start port: 10070
> voip rtp port end 14400
Set end port: 14400
> voip rtp symmetric 1
Set symmetric rtp to Enable
T
T
e
e
l
l
n
n
e
e
t
t
C
C
o
o
m
m
m
m
a
a
n
n
d
d
:
:
v
v
o
o
i
i
p
p
s
s
i
i
p
p
This command allows users to set SIP account.
S
S
y
y
n
n
t
t
a
a
x
x
