on – Enable
off - Disable
thr It means the way that VPN connection passes through. Available
settings are wlf, wlo, w2f, and w2o.
w1f – WAN1 First.
w1o – WAN1 Only.
w2f – WAN2 First.
w2o – WAN2 Only.
nnpkt It means the NetBios Naming Packet.
on – Enable the function to pass the packet.
off – Disable the function to block the packet.
dir It means the call direction. Available settings are b, o and i.
b – Both
o – Dial-Out
i – Dial-In.
idle=[value] It means Always on and Idle Time out.
Available values include:
-1 – it means always on for dial-out.
0 – it means always on for dial-in.
Other numbers (e.g., idle=200, idle=300, idle=500) mean the router
will be idle after the interval (seconds) configured here.
palive It means to enable PING to keep alive.
-1 – disable the function.
1,2,3,4 – Enable the function and PING IP 1.2.3.4 to keep alive.
For Dial-Out Settings
ctype It means “Type of Server I am calling”.
“ctype=t” means PPTP.
“ctype=s” means IPSec.
“ctype= l” means L2TP(IPSec Policy None).
“ctype= l1” means L2TP(IPSec Policy Nice to Have).
“ctype= l2” means L2TP(IPSec Policy Must).
dialto It means Server IP/Host Name for VPN. (such as draytek.com or
123.45.67.89).
ltype It means Link Type.
“ltype=0” means “Disable”.
“ltype=1” means “64kbps”.
“ltype=2” means “128kbps”.
“ltype=3” means “BOD”.
oname It means Dial-Out Username.
“oname=admin” means to set Username = admin.
opwd It means Dial-Out Password
“opwd=1234” means to set Password = 1234.
pauth It means PPP Authentication.
“pauth=pc” means to set PPP Authentication = PAP&CHAP.
“pauth=p” means to set PPP Authentication = PAP Only
ovj It means VJ Compression.
“ovj=on/off” means to enable/disable VJ Compression.
okey It means IKE Pre-Shared Key.
“okey=abcd” means to set IKE Pre-Shared Key = abcd.
