Replacing Consumables
Replacing Drum Unit
Replacing Drum Unit
● Avoid pressing and damaging the drum surface with fi ngers etc. It can stain your clothes
and the warp in the drum surface may cause bad prints.
● Always place the drum unit on a fl at and stable surface. Otherwise, the drum surface may
be damaged or warped and may cause bad prints.
Open the “front cover”.
Press the drum removal button.
● LED lights up : The drum can be removed.
● LED blinks: The drum cannot be removed.
● LED goes out: The drum is rotating. It cannot be
removed.
How to Remove Drum Unit
● Do not touch the drum or rollers when you
operate the drum removal button.
● Do not put your hands or fi ngers inside the
machine while it is operating. Your hands
or fi ngers may be pulled in and nipped.
Continue Page....
WARNING
REFERENCE
V3M0524
V3M0525
To Next Page
