16
Document/Printing Paper Specifi cations
Acceptable Documents
● The following types of document cannot be used :
* Documents with large fi le-binding holes
* Documents with staples or paper clips attached
* Documents with markedly curling ends/sides, or marked folds
* Documents with tears or rough edge
* Chemically treated documents with such as thermal paper and carbon paper, etc.
* Highly transparent documents such as OHP fi lm and tracing paper, etc.
* Documents which surface is slippery such as art paper and coated paper, etc.
* Documents with correction fl uid and glue, etc.
* Documents with smaller pieces of glued paper
Acceptable Printing Paper
● Always use documents of the same size. If you load documents in different length, the
printer may not operate correctly.
● Feed tray / Print tray
* Paper weight : 45gsm - 210gsm
* Paper size : 297mm × 432mm (max. ) (The main unit can feed up to “320mm×450mm”.)
100mm × 148mm (min.)
* Paper stacking capacity : 297mm × 432mm (max. )
100mm × 148mm (min.)
(The main unit can feed up to “320mm×450mm”.)
1500 sheets may not be loaded depending on paper condition such as paper type, etc.
Recycled paper of 100% recycled pulp with different basis weight can be used.
●
Document glass plate
Documents and books not exceeding 10kg
Document Size : 297mm × 432mm (max.)
●
Automatic document feeder (ADF) (optional)
Document weight : 64gsm - 128gsm
Document size : 297mm × 432mm (max.)
100mm × 148mm (min.)
Stacking capacity in document tray : 100 sheets (64gsm), 85 sheets (80gsm)
IMPORTANT
To Next Page
