Part Names and Their Functions
Outside/Inside of print output side
No. Name Function Reference
23
Master ejection
box open button
Press to open the master ejection box.
169, 186,
187
24 Paper eject switch
Press and hold to rotate the drum for the set time.
Use to remove paper jams, etc.
186,
187,188
25 Power switch Press to switch the power ON and OFF. 14
26
Master ejection
box cover open
lever
Press to open the master ejection box cover.
Use when disposing of used master, etc.
169
27
Master ejection
core
Use when disposing of used master. 169
28
Master ejection
box cover
Open when disposing of used master. 169
27
23
24
25
26
28
Master ejection section
V3M0105
V3M0106
