Set-up instructions
98 Operating manual 867 Version 01.0 - 12/2012
Efka controller Additional step for Efka controllers:
7. Check and set the following parameters:
• F-290 as per Parameter sheet 9800 331104 PBXX
• F-111 set to 3,000 RPM or less
• F-270 set to 6 (position sensor selection)
• F-272 to be calculated according to the following formula:
With DAC controllers the parameters are automatically set via
transfer of the machine ID.
8. Fit the valve cover and screw tight.
9. Check the setting of the Hall sensor:
Correct setting
The magnet is located directly above the Hall sensor when
the needle tip reaches the throat plate.
If this is not the case then the handwheel must be readjusted.
For more information see Service manual.
10. Fit the handwheel cover and handwheel and screw tight.
Motor belt pulley diameter (teeth)
Machine belt pulley diameter (teeth)
x 1000
