DURKOPP ADLER 867 Operating Manual

Performance description
Operating manual 867 Version 01.0 - 12/2012 15
Short arm 2-needle machines
Submodels: 867-
-260122 -290020 -290040 -290122 -290142 -290322 -290342 -290445 -490322
Sewing stitch type Double lockstitch 301
Vertical hook, large (L) x x x x x
Vertical hook, extra-large (XXL) x x x x
Number of needles 2
Needle system 134-35
Maximum needle strength [Nm] 130 180
Maximum sewing thread size
80/3 – 10/3 15/3
80/3
–
10/3
Stitch length, forwards / backwards
[mm]
7 / 7 12 / 12
Adjustable stitch lengths 1 2
Maximum number of stitches 3400 3500 3200 3500 3200 3000
Number of stitches on delivery 3400 3000
Maximum fan height (*only with
reversing mechanism)
16* 20 20*
Maximum sewing foot stroke 9
Positive operating pressure [bar] 6
Air consumption [NL] 0.7
Length/width/height [mm] 690/220/460
Weight/with direct drive [kg] 55/59
Rated voltage [V/Hz] Depends on the drive package
Rated power [kVA] Depends on the drive package

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
