DURKOPP ADLER 867 Operating Manual

Performance description
16 Operating manual 867 Version 01.0 - 12/2012
Machines with integrated motor
Submodels: 867-
-190142-M -190322-M -190342-M
Sewing stitch type Double lockstitch 301
Vertical hook, large (L) x
Vertical hook, extra-large (XXL) x x
Number of needles 1
Needle system 134-35
Maximum needle strength [Nm] 180
Maximum sewing thread size 80/3 – 10/3
Stitch length, forwards / backwards
[mm]
12 / 12
Adjustable stitch lengths 1 2
Maximum number of stitches 3400 3800 3400
Number of stitches on delivery 3400
Maximum fan height
(*only with reversing mechanism)
20*
Maximum sewing foot stroke 9
Positive operating pressure [bar] 6
Air consumption [NL] 0.7
Length/width/height [mm] 740/220/460
Weight/with direct drive [kg] 58
Rated voltage [V/Hz] 230 V - 50/60 Hz
Rated power [kVA] 375 W

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
