Performance description
Operating manual 867 Version 01.0 - 12/2012 17
Long arm 1-needle machines
Submodels: 867-
-190020-70
-190040-70
-190122-70
-190322-70
-190342-70
Sewing stitch type Double lockstitch 301
Vertical hook, large (L) x x x
Vertical hook, extra-large (XXL) x x
Number of needles 1
Needle system 134-35
Maximum needle strength [Nm] 180
Maximum sewing thread size 80/3 – 10/3
Stitch length, forwards / backwards
[mm]
12 / 12
Adjustable stitch lengths 1 1 1 2 2
Maximum number of stitches 3000
Number of stitches on delivery 3000
Maximum fan height
(*only with reversing mechanism)
20 20 20* 20*
20*
Maximum sewing foot stroke 9
Positive operating pressure [bar] 6
Air consumption [NL] 0.7
Length/width/height [mm] 1090/220/460
Weight/with direct drive [kg] 85/89
Rated voltage [V/Hz] Depending on the drive package
Rated power [kVA] Depending on the drive package
