DURKOPP ADLER 867 Operating Manual

Maintenance
Operating manual 867 Version 01.0 - 12/2012 69
Figure 44: Oil level indicator
Topping up with oil
Pour in oil through the refill opening (1) as required:
1. Switch off the sewing machine at the main switch.
2. Pour in oil, up to but not past the maximum level marking (2).
3. Switch on the sewing machine at the main switch.
CLASSIC
equipment
Note for machines with CLASSIC equipment:
If the oil level falls below the minimum level marking (3), on
CLASSIC machines the oil level indicator lights up in red.
1. Switch the sewing machine off and on again after filling with oil.
The red light goes out.
MAX
MIN
1
2
3
(1) - Refill opening
(2) - Maximum level marking
(3) - Minimum level marking

DURKOPP ADLER 867 Specifications

General

Stitch Type	Lockstitch
Max Stitch Length	12 mm
Needle System	134-35
Needle Thread Tension	Adjustable
Lubrication	Automatic
Type	Industrial Sewing Machine
Max Sewing Speed	3000 stitches per minute
Presser Foot Lift	20 mm
Power Requirements	230V/50Hz
