APPENDIX D
Ramp Installation—Dyno
Above Ground Model 200iX/250iX Motorcycle Dynamometer Installation Guide
D-8
2 Remove the four 1/4-inch button-head bolts from the top of the dyno.
3 Remove the two 3/8-inch button-head bolts from the back of the dyno.
Figure D-8: Remove the Bolts from the Dyno
remove two
back bolts
remove four
top bolts
