Eaton easy500, easy700

4 Wiring  with
4.11 Jumps
136 Operating instructions 05/10 MN05013003Z-EN www.eaton.com
4.11.2 Power Flow Display
Jumped sections are indicated by the coils in the power flow display.
All coils after the jump coil are shown with the symbol :
: of the jump coil.
4.11.2.1 Example
A selector switch allows two different sequences to be set.
• Sequence 1: Switch on motor 1 immediately.
• Sequence 2: Switch on Guard 2, Wait time, then switch on Motor 1.
Contacts and relays used:
• I1 sequence 1
• I2 sequence 2
• I3 guard 2 moved out
• I12 motor protective circuit breaker switched on
• Q1 motor 1
• Q2 guard 2
• T1 wait time 30.00 s, on-delayed
• D1 text “Motor protective circuit breaker tripped”
Circuit diagram: Power flow display: I1 selected:
Section from jump label 1 processed.
Jump to label 8.
Section to jump label 8 skipped.
Jump label 8, circuit diagram processed from
this point on.
I1-------Ä:1
I2-------Ä:2
:1
--------uÄQ1
hRQ2
---------Ä:8
:2-------ÄQ2
Q2-I3----TT2
T2-------ÄQ1
:8
I12-------
ÄD1
I1-------Ä:1
I2------- :
:1
--------uÄQ1
hRQ2
---------Ä:8
:2------- :
Q2-I3---- :
T2------- :
:8
I12------ÄD1
