3 Placing into operation
3.4 Creating your first circuit diagram
Operating instructions 05/10 MN05013003Z-EN www.eaton.com 57
3.4.4 Testing the circuit diagram
▶ Switch with ESC to the main menu and select the STOP å RUN menu
option.
With
STOP RUN å and STOP å RUN you switch to the RUN or STOP
operating modes.
easy is in RUN mode if the tick is present at the corresponding menu item.
i.e.
STOP RUN å.
▶ Press OK.
The tick changes to "STOP RUN
å"
The Status display shows the current mode and the switching states of the
inputs and outputs.
▶ Change to the Status display by pressing ESC and press pushbutton
actuator S1.
The contacts for inputs I1 and I2 are activated and relay Q1 picks up.
3.4.4.1 Power Flow Display
easy allows you to check rungs in RUN mode. This means that you can
check your circuit diagram via the built-in power flow display while it is being
processed by easy.
▶ Switch to the circuit diagram display (confirm
PROGRAM menu with OK) and
actuate pushbutton S1.
The relay picks up and easy displays the power flow.
▶ Press pushbutton actuator S2, that has been connected as the N/C
contact.
The power flow is interrupted and relay Q1 drops out.
Press ESC to return to the Status display.
PROGRAM.. .Æ
STOP å RUN
PARAMETERS..
INFO... æ
￫
The tick next to a menu item indicates which operating mode or
function is currently active.
PROGRAM.. .Æ
STOP RUN å
PARAMETERS..
INFO... æ
12..........
I
MO 02:00
1....... RUN
￫
A circuit diagram does not have to be completed before you can
test parts of it with easy.
easy simply ignores any incomplete wiring that is not yet
working and only uses the finished wiring.
