Eaton easy500, easy700

8 Appendix
8.4 List of the function relays
222 Operating instructions 05/10 MN05013003Z-EN www.eaton.com
8.4 List of the function relays
8.4.1 Usable contacts
Switching contact N/O N/C easy500 easy700 Page
Analog value comparator function
relay
A A A1…A16 A1…A16 82
Counter function relays
CSA C C1…C16 C1…C16 94
Text display function relay D D1…D16 D1…D16 109
weekly timer function relays Ö ö Ö1?Ö8 Ö1?Ö8 113
easy input terminal I I I1…I8 I1…I12 66
0 signal I13 I13
Expansion status – I14 194
Short-Circuit/Overload
I16 I15…I16 192
Markers, (auxiliary relay) M M M1…M16 M1…M16 72
Markers (auxiliary relay) N N1…N16 N1…N16
Operating Hours Counter O O1…O4 O1…O4 118
Cursor button P P P1…P4 P1…P4 70
easy output q ? Q1…Q4 Q1…Q8 66
Input terminal for expansion unit R – R1…R12 66
Short-circuit/overload with
expansion
R – R15…R16 192
easy output (expansion or S
auxiliary marker)
CSA S1…S8
(as marker)
S1…S8 72
Timer function relays
T T T1…T16 T1…T16 122
Jump label
: – :1…:8 :1…:8 135
Year Time Switch Y Y1…Y8 Y1…Y8 137
Master reset, (central reset)
Z Z1…Z3 Z1…Z3 147
D
N
O
R
R
S
Y
Z
