Eaton easy500, easy700

4 Wiring  with
4.14 Basic circuits
152 Operating instructions 05/10 MN05013003Z-EN www.eaton.com
4.14.7 Parallel circuit operating like a series connection of break contacts
A series circuit with more than three contacts (N/C contacts) can be
implemented with a parallel connection of N/O contacts on a negated coil.
In the easy circuit diagram you can switch as many rungs in parallel as you
have rungs available.
Table 22: Parallel connection of N/O contacts on a negated coil
4.14.8 Two way switch
A two-way circuit is made in easy using two series connections that are
combined to form a parallel circuit (XOR).
An XOR circuit stands for an “Exclusive Or” circuit. The coil is only energized
if one contact is activated.
Table 23: Two-way circuit (XOR)
I1u------ÅQ1
I2s
I3s
I4s
I5k
I1 I2 I3 I4 I5 Q1
000001
000010
00010
0
000110
001000
00101
0
00110
0
001110
010000
010010
……………0
……………0
111110
I1-I2u---ÄQ1
I1-I2k
I1 I2 Q1
000
01
1
101
110
