4 Wiring with
4.12 Year Time Switch
Operating instructions 05/10 MN05013003Z-EN www.eaton.com 139
4.12.5 Changing time switch channel
You can change time switch channel in either RUN or STOP mode by
selecting the channel required with the cursor buttons
ÍÚ
Example:
The display on the left shows the parameter display of a year time switch.
The cursor is flashing on channel
A.
▶ Press the
Í button to move the cursor to channel B.
You can use the
í button to reach any editable value.
Y4 A +
ON 04.01.01
OFF 04.03.31
â
Y4 B +
ON 04.10.01
OFF 04.12.31
#
Caution - important input rules!
The year time switch only operates correctly if you observe the
following rules:
• The On year must be before the Off year,
• ON and OFF times must be specified the same in pairs.
Example of entries in pairs:
• ON = Day/--/--, OFF = Day/--/--
The ON day should normally have a smaller value than the OFF
day, otherwise the special case applies
(￫ section “ Example 8: Selecting a time range of two days
spanning the turn of the year (2-channel)”, page 145).
• ON = --/--/Year, OFF = --/--/Year,
• ON = --/Month/Year, OFF = --/Month/Year
• ON = Day/Month/Year, OFF = Day/Month/Year
