8.4.4 Names of function relay
8.4.5 Name of function block inputs
(constants, operands)
8.5 Compatibility of the function relay parameters
The function relays of the easy400 and easy600 devices have been
transferred to the easy500 and easy700 with enhanced functions. The
parameter displays were adapted for the additional functions.
8.5.1 Parameter display of analog value comparator
Function
relay coil
Meaning of abbreviation Description
C count input Counter input, counter
D direction input Counter direction, counter
H hold, stop
Stopping of timing relay, stop, timing relay
R reset Reset of actual value to zero, operating hours counters, counters,
text displays, timing relays
T trigger
Timing coil, timing relay
Input Meaning of abbreviation Description
F1 Factor 1 Gain factor for I1 (I1 = F1 x Value)
F2 Factor 2 Gain factor for I2 (I2 = F2 x Value)
HY Hysteresis Switching hysteresis for value I2 (Value HY applies to positive
and negative hysteresis.)
D Day
Day
I1 Input 1 1st setpoint, comparison value
I2 Input 2 2nd setpoint, comparison value
S Setpoint
Setpoint, limit value
easy400, easy600
parameters
easy500, easy700
parameters
AA =I1 AA
BB = I2 BB
A1 = A1
+ = +
> = GE
ANALOG
AAw g
n > dA1
BByb +
A1 GE +
I1 AA Æ
F1 +0
I2 BB æ
F2 +0
OS +0
HY +0
