Eaton easy500, easy700

2 Installation
2.6 Connecting outputs
Operating instructions 05/10 MN05013003Z-EN www.eaton.com 43
2.6.1.2 EASY7..-..-R.. and EASY202-RE
Figure 29: EASY7..-..-R.. relay outputs and EASY202-RE
2.6.1.3 EASY618-..-RE
Figure 30: EASY618…-…-RE… relay outputs
Unlike the inputs, the outputs can be connected to different phases.
￫
The EASY202-RE cannot be operated on an EASY7..-DA-R.. with
a 12 V DC power supply.
+ 24 V H
0 V H, N
F
8 A/B 16
L1, L2, L3 (115/230 V h)
12 2 2 2 2 2
1
1
1
1
1
10 000 000
Q6Q5Q4Q3
Q2
Q1
F 8 A/B 16
+ 24 V H
0 V H, N
L1, L2, L3 (115/230 V
h )
12 2
1
10 000 000
S2
S1

DANGER
Do not exceed the maximum voltage of 250 V AC on a relay
contact.
If the voltage exceeds this threshold, flashover may occur at the
contact, resulting in damage to the device or a connected load.
0 V H, N
F
8 A/B 16
L1, L2, L3 (115/230 V h)
+ 24 V H
25 000
RL
24 V H
8A
115 V h 8A
230 V h 8A
2A
2A
2A
1000 W
10 x 58 W
12 2 2 2 2 2
1
1
1
1
1
10 000 000
S6S5S4S3
S2
S1
