4 PKE-SWD-32, interface for motor-starter combination with PKE PKE12/32
4.9 Programming
112 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
Table 10: Set I
r
current value of the overload release
4.9.1.5 Trip reason (TRIPR)
In the event of a malfunction or interruption of the main circuits due to a fault
scenario, the trip reason of the interruption is indicated via the TRIPR bit field.
The following trip reasons are shown by the TRIPR bit field:
Table 11: Bit field trip reason TRIPR
Apart from the trip reason 0x5 “Overload with activated ZMR function”, the
transferred trip reasons are then reset if the main contacts of the PKE are
reclosed and a current flow is sensed through the PKE trip block.
The trip reason 0x5 “Overload with activated ZMR function” is reset if the
thermal motor image (TH) is below 100 %.
Field Value PKE-XTUA-1,2
I
r
[A]
PKE-XTUA-4
I
r
[A]
PKE-XTUA-12
I
r
[A]
PKE-XTUA-32
I
r
[A]
Ir
0x0 0.30 1.00 3.00 8.00
0x1 0.33 1.10 3.30 8.80
0x2 0.36 1.20 3.60 9.70
0x3 0.40 1.30 4.00 10.50
0x4 0.43 1.42 4.30 11.50
0x5 0.47 1.55 4.70 12.50
0x6 0.50 1.70 5.00 13.50
0x7 0.56 1.90 5.60 15.00
0x8 0.63 2.10 6.30 17.00
0x9 0.70 2.40 7.00 19.00
0xA 0.77 2.60 7.70 20.50
0xB 0.83 2.80 8.30 22.00
0xC 0.90 3.00 9.00 24.00
0xD 1.00 3.30 10.00 27.00
0xE 1.10 3.70 11.00 29.00
0xF 1.20 4.00 12.00 32.00
Field Value Description Notes
TRIPR 0x0 Not defined –
0x1 Overload PKE has switched off
0x2 Short-circuit PKE has switched off
0x3 Phase failure/
Phase Imbalance
Disconnection at 100 % of the thermal motor image
(TH)
0x4 Test position on PKE-XTUA PKE has switched off
0x5 Overload with activated
ZMR function
Contactor has switched off, the value of the
thermal motor image (TH) is still greater than
100 % after switch off
0x6 Not defined –
0x7 Not defined –
