4 PKE-SWD-32, interface for motor-starter combination with PKE PKE12/32
4.9 Programming
122 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
Object 3 [Index 3]:
Byte 0:
76543210
– – CLASS CLASS CLASS TYPE TYPE TYPE
Data byte
Data bit Designation Description Notes
0 0-2 TYPE Control option part
no.
ï¿« Section 4.9.1.8, "Type
of trip block (TYPE)", page
114
3-5 CLASS Set time lag ï¿« Section 4.9.1.9, "Time
delay setting (CLASS)",
page 114
6 Not used – –
7 Not used – –
ï¿«
Further information on the subject of "acyclical data transfer" is
provided in the manual MN05013002Z-EN (previous designation
AWB2723-1612en).
