5 Connection PKE-SWD for motor-protective circuit-breaker PKE12/32/65
5.10 Programming
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 137
Object 1 [Index 1]:
Byte 0:
Object 2 [Index 2]:
Byte 0:
76543210
I-REL I-REL I-REL I-REL I-REL I-REL I-REL I-REL
Data byte
Data bit Designation Description Notes
0 0-7 I-REL Motor current [%] ￫ Section
5.10.1.6, „Relative current
value (I-REL)“, page 133
76543210
TH TH TH TH TH TH TH TH
Data byte Data bit Designation Description Notes
0 0-7 TH Thermal motor
image [%]
￫ Section
5.10.1.7, „Thermal motor
image [TH]“, page 134
