5 Connection PKE-SWD for motor-protective circuit-breaker PKE12/32/65
5.10 Programming
138 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
Object 3 [Index 3]:
Byte 0:
76543210
– – CLASS CLASS CLASS TYPE TYPE TYPE
Data byte
Data bit Designation Description Notes
0 0-2 TYPE Control option part
no.
￫ Section 5.10.1.8, „Type
of trip block (TYPE)“, page
134
3-5 CLASS Set time lag ￫ Section 5.10.1.9, „Time
delay setting (CLASS)“,
page 135
6 Not used – –
7 Not used – –
ï¿«
Further information on the subject of "acyclical data transfer" is
provided in the manual MN05013002Z-EN (previous designation
AWB2723-1612en).
