Eaton SmartWire-DT SWD Series User Manual

6 PKE-SWD-CP, Connection for circuit-breaker PKE
6.10 Programming
148 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
6.10.1.4 Set value (I
r
)
The overload release value set on the PKE basic device is indicated via bit
field I
r
(input byte 1, bit 0, ..., bit 3). The value of this bit field indicates the
absolute current value of the overload release, which depends on the PKE
trip block selected. Bit field I
r
has the following meaning for the different PKE
trip blocks:
Table 25: Bit array Ir
Value
Description Remedy Notes
0x03 No communication
between PKE-SWD and
PKE trip block
Check whether the PKE trip block
used is of part no. PKE-XTU(W)ACP-
….
Field Value PKE-XTUA-36
I
r
[A]
PKE-XTU(W)A-32
I
r
[A]
PKE-XTUA-65
I
r
[A]
Ir
0x0 15.00 15.00 30.00
0x1 16.30 16.30 32.30
0x2 17.70 17.70 34.60
0x3 19.00 19.00 37.00
0x4 20.30 20.30 39.30
0x5 21.70 21.70 41.60
0x6 23.00 23.00 44.00
0x7 24.30 24.30 46.30
0x8 25.70 25.70 48.30
0x9 27.00 27.00 51.00
0xA 28.30 28.30 53.30
0xB 29.70 29.70 55.60
0xC 31.00 31.00 58.00
0xD 32.70 32.70 60.30
0xE 34.30 34.30 62.60
0xF 36.00 36.00 65.00
