6 PKE-SWD-CP, Connection for circuit-breaker PKE
6.10 Programming
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 147
Byte 6:
Byte 7:
6.10.1.2 Outputs
Byte 0:
If remote tripping is enabled with the R-TRIP output bit, there will be a trip if
the trip block phase currents exceed the values specified below:
6.10.1.3 Diagnostics
In the event of a diagnosis the module reports the following error causes
(input byte 0, bit 4 is set):
76543210
I-REL-L2 I-REL-L2 I-REL-L2 I-REL-L2 I-REL-L2 I-REL-L2 I-REL-L2 I-REL-L2
Data bit
Designation Description Notes
0-2 I-REL-L2 Relative phase current L2 ￫ Section 6.10.1.6, „Relative current
value (I-REL)“, page 149
76543210
I-REL-L3 I-REL-L3 I-REL-L3 I-REL-L3 I-REL-L3 I-REL-L3 I-REL-L3 I-REL-L3
Data bit
Designation Description Notes
0-2 I-REL-L3 Relative phase current L3 ￫ Section 6.10.1.6, „Relative current
value (I-REL)“, page 149
76543210
––––––R-TRIP–
Data bit
Designation Description Notes
0 – Not used
1 R-TRIP Remote tripping, PKE basic device
0: no remote tripping
1: Remote tripping
2-7 – Not used
PKE-XTU(W)ACP-36 PKE-XTUACP-65
single-
phase
15 A 30A
two-phase
12A 24A
three-phase
8A 16A
