Eaton SmartWire-DT SWD Series User Manual

6 PKE-SWD-CP, Connection for circuit-breaker PKE
6.10 Programming
146 SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com
Byte 2:
Byte 3:
Byte 4:
Byte 5:
76543210
I-REL-MAX I-REL-MAX I-REL-MAX I-REL-MAX I-REL-MAX I-REL-MAX I-REL-MAX I-REL-MAX
Data bit
Designation Description Notes
0-7 I-REL-MAX Relative current value of
the highest phase current
￫ Section 6.10.1.6, „Relative current
value (I-REL)“, page 149
76543210
TH TH TH TH TH TH TH TH
Data bit
Designation Description Notes
0-7 TH Thermal motor image [%] ￫ Section 6.10.1.7, „Thermal
model (TH)“, page 150
76543210
– – I>I>I>TYPETYPETYPE
Data bit
Designation Description Notes
0-2 TYPE Control option part no. ￫ Section 6.10.1.8, „Type of trip
block (TYPE)“, page 150
3-5
I> Factor for short-circuit current ￫ Section 6.10.1.9, „Short-circuit
release (I >) factor“, page 151
6
Not used - -
7
Not used - -
76543210
I-REL-L1 I-REL-L1 I-REL-L1 I-REL-L1 I-REL-L1 I-REL-L1 I-REL-L1 I-REL-L1
Data bit
Designation Description Notes
0-2 I-REL-L1 Relative phase current L1 ￫ Section 6.10.1.6, „Relative
current value (I-REL)“, page 149
