Eaton SmartWire-DT SWD Series User Manual

7 Pilot devices M22-SWD…
7.2 M22-SWD front mount
SmartWire-DT module IP20 01/20 MN05006001Z-EN www.eaton.com 165
Outputs
Byte 0:
By changing the content of bits 5 to 7, the brightness can be reduced to any of eight settings. The LED
will continue to be switched on and off via output Q0
.
Table 35: Brightness setting
Diagnostics
The module does not report a diagnosis.
76543210
SUBST PRSNT – DIAG – – – –
Bit
Designation Description
0 Not used –
1
Not used –
2
Not used –
3
Not used –
4
DIAG 0: no diagnostic alarm
5
Not used –
6
PRSNT 0: Module not available
1: Module available
7
SUBST 0: Configured module present
1: Universal module M22-SWD-NOP(C) present
76543210
DIM2 DIM1 DIM0 – – – – Q0
Bit
Designation Description
0 Q0 Activation of the LED
1
Not used –
2
Not used –
3
Not used –
4
Not used –
5
DIM0 Dimming setting adjustments (device version 02 and
higher)
6
DIM1
7
DIM2
DIM2 DIM1 DIM0
0 0 0 Full brightness
0 0 1 First dimming setting
---...
1 1 1 Eighth dimming setting
